5610104070

Dialight
RoHS
/
Package /
Category Optoelectronics / LEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Description 561 Round with Domed Top 1 Diffused LED Circuit Board Indicator 2.4V 10mA 8mcd 60°
PDF
/
Inventory: 8507
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

T-code T-1 3/4
Overall Height 17.8mm
Forward Voltage-Max 2.4V
Wavelength - Peak 635nm
Millicandela Rating 8mcd
Lens Type Diffused
Luminous Intensity 8.0 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Viewing Angle 60°
Current 10mA
Configuration Single
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 2.54mm
Number of Functions 1
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Additional Feature HIGH RELIABILITY
Voltage - Rated 5V
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Series 561
Published 2002
Packaging Bulk

Physical

Mounting Feature RADIAL MOUNT
Surface Mount NO
Mounting Type Through Hole
