SML-M13DTT86
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE CLEAR 0805 SMD
PDF
/
Buying Options
Total Price: USD $1.63
Unit Price: USD $1.62925
≥1 USD $1.62925
≥10 USD $1.33665
≥100 USD $1.29485
≥500 USD $1.25305
≥1000 USD $1.21125
Inventory: 1224
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2015
Series SML-M1
Size / Dimension 2.00mm Lx1.25mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Packing Method TR, 7 INCH
Number of Functions 1
Base Part Number SML-M13
Case Code (Metric) 2012
Case Code (Imperial) 0805
Configuration Standard
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.40mmx0.85mm
Luminous Intensity 200 mcd
Millicandela Rating 200mcd
Lens Transparency Clear
Lens Color Colorless
Wavelength - Dominant 605nm
Number of LEDs 1
Dimensions
Height 900μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
