SML-522MUWT86
RoHS
RoHS compliant
RoHS compliantPackage 0605 (1513 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED DIFFUSED 1315 SMD
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
≥10 USD $0.50512
≥100 USD $0.330968
≥500 USD $0.261307
≥1000 USD $0.243892
Inventory: 5615
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 600μm
Technical
Peak Wavelength 630/570 nm
Reverse Voltage-Max 4V
Number of LEDs 2
Wavelength - Dominant 572nm Green 620nm Red
Lens Color White
Lens Transparency Diffused
Illumination Color Green, Red
Millicandela Rating 40mcd Green, 63mcd Red
Luminous Intensity 63 mcd
Lens Size 1.10mmx1.30mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Green 20mA Red
Forward Current 20mA
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 160 °
Voltage - Forward (Vf) (Typ) 2.1V Green 1.9V Red
Configuration Independent
Case Code (Imperial) 0605
Case Code (Metric) 1513
Base Part Number SML-522
Terminal Pitch 0.9mm
Number of Functions 2
Packing Method TAPE AND REEL
Subcategory Visible LEDs
Color Green, Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 1.50mm Lx1.30mm W
Series SML-52
Published 2006
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 4
Package / Case 0605 (1513 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
