APTD3216SYCK
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED YELLOW CLEAR 2SMD
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.25432
≥100 USD $0.169664
≥500 USD $0.117322
≥1000 USD $0.097768
Inventory: 74810
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 3.20mm Lx1.60mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Gold (Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Yellow
Subcategory Visible LEDs
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 3.75mm
Case Code (Metric) 3216
Case Code (Imperial) 1206
Configuration Standard
Power Dissipation 75mW
Voltage - Forward (Vf) (Typ) 2V
Viewing Angle 35°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Round with Domed Top
Lens Size 1.60mm Dia
Luminous Intensity 800 mcd
Millicandela Rating 800mcd
Lens Transparency Clear
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 590nm
Number of LEDs 1
Max Junction Temperature (Tj) 115°C
Peak Wavelength 590 nm
Dimensions
Height 2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
