QTLP670CRYTR
RoHS
RoHS compliant
RoHS compliantPackage 4-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD Red/Yellow SMT TNR alInGaP
PDF
/
Inventory: 9075
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 2.1mm
Technical
Reverse Voltage-Max 5V
Number of LEDs 2
Wavelength - Dominant 624nm Red 589nm Yellow
Lens Color Colorless
Wavelength - Peak 630nm Red 590nm Yellow
Lens Transparency Clear
Illumination Color Red, Yellow
Millicandela Rating 35mcd Red, 35mcd Yellow
Luminous Intensity 35 mcd
Lens Size 2.00mmx2.70mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Red 20mA Yellow
Forward Current 20mA
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 2V Red 2V Yellow
Configuration Independent
Terminal Pitch 3mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
Additional Feature SUPPORTS INFRARED
Color Red, Yellow
Min Operating Temperature -40°C
Max Operating Temperature 95°C
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.20mm Lx2.80mm W
Published 2001
Packaging Tape & Reel (TR)
Physical
Shape ROUND
Number of Pins 4
Package / Case 4-PLCC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
