5988421207F
RoHS
/
Package 0606 (1616 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED Bi-Color Green/Orange Red 4-Pin SMD T/R
PDF
/
Inventory: 4709
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 700μm
Technical
Wavelength - Dominant 525nm Green 625nm Red
Wavelength 630 nm
Reverse Voltage 5V
Lens Color Colorless
Lens Transparency Clear
Illumination Color Green, Orange
Millicandela Rating 220mcd Green, 100mcd Red
Luminous Intensity 120 mcd
Lens Size 1.10mmx0.90mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Green 20mA Red
Forward Current 20mA
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 140°
Voltage - Forward (Vf) (Typ) 3.2V Green 2V Red
Configuration Independent
Number of Elements 2
Case Code (Imperial) 0606
Case Code (Metric) 1616
Depth 1.6mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
Color Green, Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Nickel/Gold (Ni/Au)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Size / Dimension 1.60mm Lx1.60mm W
Series 598
Published 2007
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 4
Package / Case 0606 (1616 Metric)
Mounting Type Surface Mount
Mount Surface Mount
