5973311407F

Dialight
RoHS
RoHS RoHS compliant
Package 1206 (3016 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED GREEN CLEAR 1206 SMD
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.146669
≥1 USD $0.146669
≥10 USD $0.138369
≥100 USD $0.130533
≥500 USD $0.123145
≥1000 USD $0.116172
Inventory: 5344
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 1206 (3016 Metric)
Surface Mount YES
Shape RECTANGULAR

Technical

Packaging Tape & Reel (TR)
Published 2002
Series 597
Size / Dimension 3.00mm Lx1.50mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Terminal Finish Copper/Nickel/Gold (Cu/Ni/Au)
Color Green
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 2.955mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -30°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 70°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Flat Top
Luminous Intensity 12.0 mcd
Millicandela Rating 12mcd
Lens Transparency Clear
Wavelength - Peak 560nm
Lens Color Colorless
Forward Current-Max 0.03A
Forward Voltage-Max 2.5V
Overall Height 1.5mm
Wavelength - Dominant 567nm
Reverse Voltage-Max 4V

Dimensions

Height (Max) 1.51mm

Compliance

RoHS Status RoHS Compliant
