C4SMK-RJS-CS44QBB1
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - Through Hole Red Oval LED
PDF
/
Inventory: 5784
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 3.9mm
Height 10.5mm
Technical
Wavelength - Dominant 621nm
Reverse Voltage 5V
Lens Transparency Clear
Millicandela Rating 1345mcd
Luminous Intensity 1.3 cd
Lens Size 3.90mmx3.00mm
Lens Style Oval with Domed Top
Current - Test 20mA
Forward Current 50mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 110 °
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 200mW
Configuration Standard
Number of Elements 1
Base Part Number C4SMK
Depth 3mm
Number of Functions 1
Subcategory Visible LEDs
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 95°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Screen Master?
Packaging Bulk
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
