HSMG-C280
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD GaP Green
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.2728
≥100 USD $0.181896
≥500 USD $0.125805
≥1000 USD $0.104843
≥3000 USD $0.094362
Inventory: 148478
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 500μm
Technical
Max Junction Temperature (Tj) 95°C
Wavelength - Dominant 572nm
Reverse Voltage 5V
Luminous Flux 595 lm
Lens Color White
Wavelength - Peak 570nm
Lens Transparency Diffused
Luminous Intensity 15 mcd
Lens Size 1.00mmx0.50mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 130°
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 52mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 0402
Case Code (Metric) 1005
Base Part Number HSMG-C280
Depth 500μm
Number of Functions 1
Max Power Dissipation 52mW
Packing Method TAPE AND REEL 7"
Power Rating 52mW
Subcategory Visible LEDs
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
JESD-609 Code e4
Size / Dimension 1.00mm Lx0.50mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
