HSMF-C169
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED AMBER/BLUE DIFFUSED 0603 SMD
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.54
≥1 USD $1.54
≥10 USD $1.02872
≥100 USD $0.791472
≥500 USD $0.71544
≥1000 USD $0.614838
≥3000 USD $0.581302
Inventory: 1583
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 4
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2007
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 4
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Amber, Blue
Subcategory Visible LEDs
Power Rating 38mW
Packing Method TAPE AND REEL 7"
Max Power Dissipation 48mW
Number of Functions 1
Terminal Pitch 1.3mm
Base Part Number HSMF-C16
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Independent
Power Dissipation 48mW
Voltage - Forward (Vf) (Typ) 1.9V Amber 3.4V Blue
Viewing Angle 120°
Optoelectronic Device Type DUAL COLOR LED
Forward Current 10mA
Current - Test 20mA Amber 10mA Blue
Lens Style Rectangle with Flat Top
Lens Size 1.60mmx0.80mm
Luminous Intensity 10 mcd
Millicandela Rating 90mcd Amber, 10mcd Blue
Illumination Color Blue, Orange
Lens Transparency Diffused
Wavelength - Peak 595nm Amber 468nm Blue
Lens Color White
Reverse Voltage 5V
Wavelength - Dominant 592nm Amber 470nm Blue
Number of LEDs 2
Dimensions
Height 500μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
