HLMP-EJ15-SV0DD

Broadcom Limited
RoHS
RoHS RoHS compliant
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description Standard LEDs - Through Hole Orange, 605nm 15 Deg, 5500mcd(max)
PDF
/
Inventory: 2467
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 8.91mm
Diameter 5mm

Technical

Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Dominant 605nm
Luminous Flux 500 mlm
Forward Current-Max 0.05A
Lens Color Colorless
Wavelength - Peak 609nm
Lens Transparency Clear
Millicandela Rating 3700mcd
Luminous Intensity 3.7 cd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 15°
Voltage - Forward (Vf) (Typ) 1.98V
Configuration Standard
Operating Temperature (Min) -40°C
Base Part Number HLMP-EJ15
Number of Functions 1
Subcategory Visible LEDs
Additional Feature HIGH RELIABILITY
Color Orange
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Box (TB)

Physical

Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
