HLMP-3750

Broadcom Limited
RoHS
RoHS RoHS compliant
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR T-1 3/4 T/H
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.40568
≥100 USD $0.268312
≥500 USD $0.207143
≥1000 USD $0.187185
≥3000 USD $0.174706
Inventory: 4425
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Length 6.1mm
Height 12.44mm
Diameter 5.08mm

Technical

Wavelength - Dominant 626nm
Forward Voltage-Max 3V
Reverse Voltage 5V
Lens Color Colorless
Wavelength - Peak 635nm
Lens Transparency Clear
Millicandela Rating 125mcd
Luminous Intensity 125 mcd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 24°
Voltage - Forward (Vf) (Typ) 1.9V
Configuration Standard
Number of Elements 1
Lead Length 23mm
Base Part Number HLMP-3750
Depth 6.1mm
Number of Functions 1
Subcategory Visible LEDs
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2003
Packaging Bulk

Physical

Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin

Supply Chain

Factory Lead Time 13 Weeks
