ASMT-QTB0-0AA02
RoHS
/
Package 4-SMD, J-Lead
Category Optoelectronics / LED Indication - Discrete
Description
AVAGO TECHNOLOGIES ASMT-QTB0-0AA02 LED, 2.9mm, Red, Green, Blue, R 620mcd, G 1.2cd, B 280mcd, 120 , R 2.1V, G 3.2V, B 3.2V
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6916
≥1 USD $0.6916
≥10 USD $0.5681
≥100 USD $0.55005
≥500 USD $0.532
≥1000 USD $0.5149
Inventory: 35004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Height 2.2mm
Technical
T-code T-1
Wavelength - Dominant 621nm Red 528nm Green 470nm Blue
Reverse Voltage 4V
Lens Color Colorless
Wavelength - Peak 629nm Red 521nm Green 465nm Blue
Lens Transparency Clear
Millicandela Rating 620mcd Red, 1200mcd Green, 280mcd Blue
Luminous Intensity 2.7 mcd
Lens Size 2.90mm Dia
Lens Style Round with Flat Top
Current - Test 20mA Red 20mA Green 20mA Blue
Forward Current 20mA
Optoelectronic Device Type TRIPLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.1V Red 3.2V Green 3.2V Blue
Configuration Common Anode
Number of Elements 3
Base Part Number ASMT-QTB0
Depth 3.2mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Power Rating 117mW
Additional Feature HIGH RELIABILITY
Color Red, Green, Blue (RGB)
Min Operating Temperature -40°C
Max Operating Temperature 110°C
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
JESD-609 Code e4
Size / Dimension 3.40mm Lx3.20mm W
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 4
Package / Case 4-SMD, J-Lead
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Silver
