LDC12-18-R70
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED CONSTANT CURRENT PS 18V 12W - More Details
PDF
/
Inventory: 7961
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP66
RoHS Status RoHS Compliant
Dimensions
Width 50.038mm
Length 195.072mm
Height 21.082mm
Technical
Current - Output 1 700mA
Topology AC DC Converter
Voltage - Output 3V~18V
Output Power 12.6W
Output Current 700mA
Current - Output (Max) 700mA
Voltage - Input (Min) 90VAC
Voltage - Output 1 18V
Max Output Current 700mA
Voltage - Input (Max) 264VAC
Voltage - Isolation 3kV
Efficiency 82%
Approval Agency CE, IEC, UL
Number of Outputs 1
Termination Style Wire Leads
Depth 34.5mm
Max Power Dissipation 13W
Power Rating 12W
Power (Watts) 13W
Min Operating Temperature -10°C
Max Operating Temperature 60°C
Type Constant Current
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OCP, OVP
Size / Dimension 3.45Lx1.36W x 0.83 H 90.0mmx34.5mmx21.0mm
Series LD12 (12W)
Published 2009
Operating Temperature -10°C~60°C
Physical
Weight 0.186lb 84.37g
Mounting Type Chassis Mount
Mount Chassis Mount
