LD20W-22-C0700
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER AC/DC CC 7-22V 700MA
PDF
/
Inventory: 3444
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP66
RoHS Status ROHS3 Compliant
Technical
Dimming Analog, PWM
Topology AC DC Converter
Voltage - Output 7V~22V
Current - Output (Max) 700mA
Voltage - Input (Min) 90VAC
Voltage - Input (Max) 305VAC
Voltage - Isolation 3.75kV
Approval Agency CE, cURus, FCC
Number of Outputs 1
Termination Style Wire Leads
Type Constant Current
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 3.74Lx1.61W x 0.98 H 95.0mmx40.9mmx24.9mm
Series LD20W
Operating Temperature -30°C~60°C
Physical
Mounting Type Chassis Mount
