ACPL-3130-560E
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD, Gull Wing
Category Isolators / Isolators - Gate Drivers
Description
Optocoupler Drive Push-Pull 1-CH 30V 1500V 8-Pin PDIP SMD T/R
PDF
/
Buying Options
Total Price: USD $4.99
Unit Price: USD $4.992959
≥1 USD $4.992959
≥200 USD $1.992982
≥500 USD $1.926024
≥1000 USD $1.893202
Inventory: 8343
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD, Gull Wing
Number of Pins 8
Technical
Operating Temperature -40°C~100°C
Packaging Tape & Reel (TR)
Published 2013
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature UL RECOGNIZED, VDE APPROVED
Subcategory Optocoupler - IC Outputs
Max Power Dissipation 295mW
Technology Optical Coupling
Supply Voltage 30V
Approval Agency CSA, IEC/EN/DIN, UR
Voltage - Isolation 3750Vrms
Max Output Current 2.5A
Number of Elements 1
Configuration COMPLEX
Number of Channels 1
Voltage - Forward (Vf) (Typ) 1.5V
Propagation Delay 500 ns
Turn On Delay Time 500 ns
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Response Time 5e-7 ns
Direction Unidirectional
Current - Output High, Low 2A 2A
Rise Time 100ns
Fall Time (Typ) 100 ns
Rise / Fall Time (Typ) 100ns 100ns
Current - DC Forward (If) (Max) 25mA
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Common Mode Transient Immunity (Min) 40kV/μs
Pulse Width Distortion (PWD) 300 ns
Voltage - Output Supply 15V~30V
Compliance
RoHS Status ROHS3 Compliant
