RoHS
RoHS compliant
RoHS compliantPackage 12-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Controllers
Description
Tape & Reel (TR) 2006 UART USB 2.0 interface controller 2.97V~5.5V 800mum 8mA 3Mbps
PDF
/
Buying Options
Total Price: USD $5.94
Unit Price: USD $5.944
≥1 USD $5.944
≥10 USD $4.84
≥100 USD $4
Inventory: 502
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Package / Case 12-VFDFN Exposed Pad
Number of Pins 12
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2006
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
Subcategory Serial IO/Communication Controllers
Technology CMOS
Voltage - Supply 2.97V~5.5V
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.45mm
Time@Peak Reflow Temperature-Max (s) 40
Function Bridge, USB to UART
Qualification Status Not Qualified
Operating Supply Voltage 5V
Interface UART
Operating Supply Current 8mA
Number of Ports 1
Nominal Supply Current 8mA
uPs/uCs/Peripheral ICs Type BUS CONTROLLER, UNIVERSAL SERIAL BUS
Data Rate 3 Mbps
Protocol USB
USB USB 2.0
Standards USB 2.0
Bus Compatibility I2C
Ambient Temperature Range High 85°C
Dimensions
Height 800μm
Length 3mm
Width 3mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
