GL514A
RoHS
/
Package TO-18-2 Metal Can
Category Optoelectronics / Infrared, UV, Visible Emitters
Description
EMITTER IR 950NM 150MA TO-18
PDF
/
Buying Options
Total Price: USD $3.59
Unit Price: USD $3.591
≥1 USD $3.591
≥10 USD $2.9469
≥100 USD $2.85475
≥500 USD $2.7626
≥1000 USD $2.67045
Inventory: 2101
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-18-2 Metal Can
Number of Pins 2
Technical
Operating Temperature -40°C~125°C TA
Packaging Bulk
Published 1997
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Infrared (IR)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Power Rating 250mW
Orientation Top View
Depth 5.7mm
Number of Elements 1
Power Dissipation 250mW
Voltage - Forward (Vf) (Typ) 1.35V
Viewing Angle 14°
Forward Current 150mA
Lens Style Circular
Test Current 100mA
Forward Voltage 1.6V
Reverse Voltage 6V
Wavelength 950nm
Current - DC Forward (If) (Max) 150mA
Dimensions
Length 5.7mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
