023902.5HXP
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 2.5A 250VAC 5X20MM
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.93104
≥100 USD $0.87032
≥500 USD $0.720192
≥1000 USD $0.60016
≥3000 USD $0.585112
Inventory: 712
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Body Height 20mm
Diameter 5mm
Technical
Fuse Class Supplemental
Trip Time or Delay 14400 s
Fuse Current 2.5A
Joule Integral-Nom 79 J
Fuse Size 5x20mm
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0583Ohm
Melting I2t 79.705
Breaking Capacity @ Rated Voltage 100A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Working Voltage 250V
Physical Dimension 5.2mm x 20mm
Approval Agency CE, CSA, KC, PSE, UL
Voltage - Rated AC 250V
Reference Standard CE; CSA; KC; PSE; UL
Current Rating 2.5A
Voltage - Rated DC 250V
Terminal Finish Nickel (Ni)
Resistance 58.3mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 239
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Glass
Terminal Shape END CAP
Package / Case 5mm x 20mm
Mounting Type Holder
Mount Clip, Holder
Supply Chain
Factory Lead Time 15 Weeks
