744765068A
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-KI 0402 (1005Metric) 0.039Lx0.022W 1.00mmx0.55mm 6.8nH
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 1888
Minimum: 1
-
+
Technical Details
Technical
Size / Dimension 0.039Lx0.022W 1.00mmx0.55mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 83mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Ceramic, Wirewound
Current Rating (Amps) 680mA
Shielding Unshielded
Depth 550μm
Current Rating 680mA
Frequency 250MHz
Case Code (Metric) 1005
Case Code (Imperial) 0402
Inductance 6.8nH
Series WE-KI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Series Resistance 83mOhm
Inductance Tolerance 5%
Q Factor 20
Inductance Frequency - Test 250MHz
Q @ Freq 20 @ 250MHz
Frequency - Self Resonant 4.8GHz
Max DC Current 680mA
DC Resistance (DCR) 83mOhm Max
Test Frequency 250MHz
Physical
Material - Core Ceramic
Weight 652.039032μg
Material Ceramic
Supplier Device Package 0402 (1005 Metric)
Number of Pins 2
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 34 Weeks
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 550μm
Length 1mm
Height Seated (Max) 0.024 0.60mm
Height 500μm
