PL9117

PulseR
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Active Tube Surface Mount fixed air core inductor -55C~130C 110mOhm Max 56muH ±20%
PDF
/
Inventory: 994
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Radiation Hardening No

Dimensions

Length 10.5mm
Height Seated (Max) 0.248 6.30mm
Height 6.3mm

Technical

DC Current 1.9A
Current - Saturation 1.9A
Max DC Current 1.9A
DC Resistance (DCR) 110mOhm Max
Inductance 56μH
Military Standard Not
Depth 10.5mm
Shielding Shielded
Current Rating (Amps) 1.9A
Min Operating Temperature -55°C
Max Operating Temperature 130°C
Resistance 110mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.413Lx0.413W 10.50mmx10.50mm
Series PL91XX
Packaging Tube
Operating Temperature -55°C~130°C

Physical

Package / Case Nonstandard
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
