1210R-223F

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package 2-SMD
Category Inductors, Coils, Chokes / Fixed Inductors
Description FIXED IND 22UH 224MA 3.7 OHM SMD
PDF
/
Inventory: 6305
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.101 2.57mm
Height 2.57mm

Technical

Q Factor 30
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 30
Q @ Freq 30 @ 2.5MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 20MHz
Max DC Current 224mA
DC Resistance (DCR) 3.7Ohm Max
Test Frequency 2.5MHz
Inductance 22μH
Current Rating 224mA
Depth 2.67mm
Number of Functions 1
Shielding NO
Packing Method TR, 7 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±1%
Size / Dimension 0.128Lx0.095W 3.26mmx2.41mm
Series 1210R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 2
Terminal Shape J BEND
Package / Case 2-SMD
Mounting Type Surface Mount
Mount Surface Mount
