108-273K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active Contains Lead Fixed Inductor -55C~125C 14MHz 8Ohm Max 27muH
PDF
/
Inventory: 10011
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Iron
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2002
Series 108
Size / Dimension 0.100Lx0.100W 2.54mmx2.54mm
Tolerance ±10%
JESD-609 Code e4
Pbfree Code no
Part Status Active
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 1
Depth 2.79mm
Construction Rectangular
Current Rating 55mA
Inductance 27μH
Test Frequency 2.5MHz
DC Resistance (DCR) 8Ohm Max
Max DC Current 55mA
Frequency - Self Resonant 14MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 32 @ 2.5MHz
Quality Factor-Min (at L-nom) 32
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 32
Case/Size Code 0101
Dimensions
Height 1.91mm
Height Seated (Max) 0.075 1.91mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
