1008R-820K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
1008R Nonstandard 0.105Lx0.095W 2.66mmx2.41mm 82nH
PDF
/
Buying Options
Total Price: USD $4.66
Unit Price: USD $4.6552
≥1 USD $4.6552
≥10 USD $3.76904
≥100 USD $3.349984
≥500 USD $3.163952
≥1000 USD $2.93128
≥3000 USD $2.884781
Inventory: 802
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.095 2.41mm
Height 2.41mm
Technical
Q Factor 25
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 25
Q @ Freq 25 @ 50MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 915MHz
Max DC Current 801mA
DC Resistance (DCR) 190mOhm Max
Test Frequency 50MHz
Inductance 82nH
Case Code (Imperial) 1008
Case Code (Metric) 2520
Current Rating 801mA
Construction Rectangular
Depth 2.66mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±10%
Size / Dimension 0.105Lx0.095W 2.66mmx2.41mm
Series 1008R
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape J BEND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 45 Weeks
