BLM21BB750SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
EMI Filter Beads, Chips & Arrays 0805 75ohms HiSpeed Signal Line Tape
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.15459
≥1 USD $0.15459
≥10 USD $0.145845
≥100 USD $0.137583
≥500 USD $0.129804
≥1000 USD $0.122458
Inventory: 7180
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Material Ferrite
Technical
Packaging Tape & Reel (TR)
Series EMIFIL?, BLM21
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 75Ohm
Max Operating Temperature 125°C
Min Operating Temperature -55°C
HTS Code 8504.50.80.00
Subcategory Other Filters
Shielding Unshielded
Number of Functions 1
Construction Chip Bead
Test Frequency 100MHz
DC Resistance (DCR) 250mOhm
Impedance 75Ohm
Max DC Current 200mA
Filter Type Differential Mode - Single
Rated Current 0.2A
Number of Lines 1
Impedance @ Frequency 75Ohm @ 100MHz
Dimensions
Height 850μm
Length 2mm
Compliance
RoHS Status ROHS3 Compliant
