BLM21BB331SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads Multi-Layer 330Ohm 25% 100MHz 200mA 400mOhm DCR 0805 Paper T/R
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.153105
≥1 USD $0.153105
≥10 USD $0.144439
≥100 USD $0.136265
≥500 USD $0.128548
≥1000 USD $0.121275
Inventory: 1479
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 850μm
Technical
Impedance @ Frequency 330Ohm @ 100MHz
Number of Lines 1
Filter Type Differential Mode - Single
Max DC Current 200mA
Impedance 330Ohm
DC Resistance (DCR) 400mOhm
Test Frequency 100MHz
Case Code (Imperial) 0805
Case Code (Metric) 2012
Construction Chip Bead
Number of Functions 1
Shielding Unshielded
Subcategory Other Filters
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 400mOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMIFIL?, BLM21
Packaging Tape & Reel (TR)
Physical
Core Material Ferrite
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
