BLM18HD471SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
EMI Filter Beads, Chips & Arrays 0603 470ohms GHz Hi Speed Sig Line Tape
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.031487
≥10 USD $0.031487
≥100 USD $0.025745
≥300 USD $0.022875
≥1000 USD $0.020721
≥4000 USD $0.018999
≥8000 USD $0.018137
Inventory: 1363
Minimum: 10
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 0.8mm
Height 800μm
Technical
Impedance @ Frequency 470Ohm @ 100MHz
Number of Lines 1
Filter Type Differential Mode - Single
Max DC Current 100mA
Impedance 470Ohm
DC Resistance (DCR) 1.2Ohm
Test Frequency 100MHz
Construction Chip Bead
Number of Functions 1
Shielding Unshielded
Subcategory Other Filters
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Resistance 470Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMIFIL?, BLM18
Packaging Tape & Reel (TR)
Physical
Material Ferrite
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
