BLM18AG331SN1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
FERRITE BEAD 330 OHM 0603 1LN
PDF
/
Buying Options
Total Price: USD $0.02
Unit Price: USD $0.01805
≥1 USD $0.01805
≥10 USD $0.0152
≥100 USD $0.0152
≥500 USD $0.01425
≥1000 USD $0.01425
Inventory: 8806
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 0.8mm
Height 800μm
Technical
Impedance @ Frequency 330Ohm @ 100MHz
DC Resistance (DCR) (Max) 300mOhm
Number of Lines 1
Max DC Current 500mA
Impedance 330Ohm
Test Frequency 100MHz
ESR (Equivalent Series Resistance) 330Ohm
Case Code (Imperial) 0603
Case Code (Metric) 1608
Current Rating 500mA
Construction Chip Bead
Depth 800μm
Number of Functions 1
Shielding Unshielded
Subcategory Other Passive Filters
HTS Code 8504.50.80.00
Additional Feature MONOLITHIC TYPE
Terminal Finish Tin (Sn)
Resistance 300mOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMIFIL?, BLM18
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Material Ferrite, Steel
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 6 Weeks
