BLM02AX700SN1D
RoHS
RoHS compliant
RoHS compliantPackage 01005 (0402 Metric)
Category Filters / Ferrite Beads and Chips
Description
EMI Filter Beads, Chips & Arrays 01005 70ohm +/- 25% Ic=300mA
PDF
/
Buying Options
Total Price: USD $0.02
Unit Price: USD $0.01615
≥1 USD $0.01615
≥10 USD $0.0133
≥100 USD $0.0133
≥500 USD $0.01235
≥1000 USD $0.01235
Inventory: 1468
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 01005 (0402 Metric)
Number of Pins 2
Material Steel
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, BLM02
Size / Dimension 0.016Lx0.008W 0.40mmx0.20mm
Tolerance 25%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 70Ohm
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Subcategory Other Filters
Packing Method TR, 7 INCH
Number of Functions 1
Construction Chip Bead
Current Rating 300mA
Case Code (Metric) 0402
Case Code (Imperial) 1005
Test Frequency 100MHz
Impedance 70Ohm
Max DC Current 300mA
Filter Type FERRITE CHIP
Number of Lines 1
DC Resistance (DCR) (Max) 360mOhm
Impedance @ Frequency 70Ohm @ 100MHz
Dimensions
Height 200μm
Length 0.4mm
Compliance
RoHS Status ROHS3 Compliant
