NFM21PC105B1C3D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
MURATA - NFM21PC105B1C3D - Feedthrough Capacitor, Three Terminal, 1 μF, 16 V, 4 A, 0805 [2012 Metric], Surface Mount, ± 20%
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.076
≥1 USD $0.076
≥10 USD $0.0627
≥100 USD $0.0608
≥500 USD $0.0589
≥1000 USD $0.057
≥4000 USD $0.0513
Inventory: 393428
Minimum: 1
-
+
Technical Details
Technical
Case Code (Metric) 2012
Case Code (Imperial) 0805
Physical Dimension L2.0XB1.25XH0.85 (mm)/L0.079XB0.049XH0.033 (inch)
Insulation Resistance 500MOhm
Voltage 16V
Max Current Rating 4A
Max Voltage Rating (DC) 16V
Filter Type FEED THROUGH CAPACITOR
DC Resistance (DCR) (Max) 20mOhm
Voltage - Rated AC 16V
Current Rating 4A
Depth 1.25mm
Number of Functions 1
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 16V
Capacitance 1μF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination Flat
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMIFIL?, NFM21
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Height 850μm
Length 2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Package / Case 0805 (2012 Metric), 3 PC Pad
Mounting Type Surface Mount
Mount PCB, Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 10 Weeks
