SFBMC5000221MC1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFBM Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 6.35mm 10dB @ 100MHz
PDF
/
Inventory: 8162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type PANEL MOUNT
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series SFBM
Size / Dimension 0.250Diax0.472L 6.35mmx12.00mm
Tolerance ±20%
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient C0G NP0
Terminal Finish SILVER
Voltage - Rated 500V
Additional Feature C-TYPE CIRCUIT
Capacitance 220pF
Number of Functions 1
Physical Dimension D6.35XH12.0 (mm)/D0.25XH0.472 (inch)
Current 10A
Filter Type FEED THROUGH CAPACITOR
Thread Size M5x0.8
Insertion Loss 10dB @ 100MHz
Insulation Resistance-Min 10000MOhm
Dimensions
Diameter 6.35mm
Height 12mm
Compliance
RoHS Status ROHS3 Compliant
