54-790-018 image
Favorite
54-790-018 image
Favorite
RoHS
/
Package Axial, Bushing
Category Filters / Feed Through Capacitors
Description EMI Feedthrough Filters 10A 1000pF 4-40
PDF
/
Buying Options
Total Price: USD $6.4
Unit Price: USD $6.401108
≥1 USD $6.401108
≥10 USD $6.038782
≥100 USD $5.696966
≥500 USD $5.374501
≥1000 USD $5.070282
Inventory: 1182
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Height 8.64mm
Diameter 3.96mm

Technical

Insertion Loss (dB) 20 dB
Insertion Loss 20dB @ 100MHz
DC Resistance (DCR) (Max) 10mOhm
Thread Size 4-40
Filter Type FEED THROUGH CAPACITOR
Current 10A
Physical Dimension D3.96XH8.64 (mm)/D0.156XH0.34 (inch)
Number of Functions 1
Capacitance 1000pF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 300V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Size / Dimension 0.156Diax0.340L 3.97mmx8.64mm
Packaging Bulk
Operating Temperature -55°C~125°C

Physical

Package / Case Axial, Bushing
Mounting Type Chassis Mount
Mount Chassis Mount

Supply Chain

Factory Lead Time 10 Weeks
