54-786-013
RoHS
/
Package Axial, Bushing
Category Filters / Feed Through Capacitors
Description
EMI Feedthrough Filters 10A .3uF 10-32
PDF
/
Buying Options
Total Price: USD $9.26
Unit Price: USD $9.261678
≥1 USD $9.261678
≥10 USD $8.737434
≥100 USD $8.242856
≥500 USD $7.776289
≥1000 USD $7.336115
Inventory: 8797
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height 9.5mm
Diameter 5.54mm
Technical
Insertion Loss (dB) 60 dB
Insertion Loss 60dB @ 100MHz
DC Resistance (DCR) (Max) 10mOhm
Thread Size 10-32
Filter Type FEED THROUGH CAPACITOR
Circuit Type Filter
Max DC Current 10A
Lead Diameter 130 μm
Physical Dimension D5.54XH9.5 (mm)/D0.218XH0.374 (inch)
Number of Functions 1
Capacitance 0.3μF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 50V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Tolerance 0% +100%
Size / Dimension 0.218Diax0.374L 5.54mmx9.50mm
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 10 Weeks
