AEDB-9140-E11

Broadcom Limited
RoHS
RoHS RoHS compliant
Package /
Category Sensors, Transducers / Encoders
Description Encoders 3 Channel 200CPR Metal CW 28mm 4mm
PDF
/
Inventory: 9180
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Chassis Mount, Motors
Surface Mount NO
Mounting Feature THROUGH HOLE MOUNT

Technical

Series AEDB-9140
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Voltage - Supply 5V
Number of Functions 1
Reach Compliance Code compliant
Termination Style Terminal Pins
Operating Temperature (Max) 85°C
Actuator Type 4mm Open Center
Operating Temperature (Min) -10°C
Output Type Quadrature with Index (Incremental)
Configuration SINGLE, 3 CHANNELS
Optoelectronic Device Type ROTARY POSITION ENCODER
Encoder Type Optical
Detent No
Pulses per Revolution 200

Compliance

RoHS Status RoHS Compliant
