P89V662FBC,557
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit P89 80C51 CISC 32KB Flash 5V 44-Pin TQFP Tray
PDF
/
Inventory: 10020
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.2mm
Technical
External Data Bus Width 8
ROM (words) 32768
Address Bus Width 16
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC NO
Bit Size 8
Supply Current-Max 50mA
Connectivity I2C, SPI, UART/USART
Program Memory Size 32KB 32K x 8
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 40MHz
Peripherals POR, PWM, WDT
Core Processor 8051
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
RAM Size 1K x 8
Speed 40MHz
Number of I/O 36
Oscillator Type Internal
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G44
Pin Count 44
Base Part Number P89V66*
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Series 89V
Published 2007
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 44-TQFP
Mounting Type Surface Mount
