LFE2M20E-7F484C image
Favorite
LFE2M20E-7F484C image
Favorite
RoHS
/
Package 484-BBGA
Category Integrated Circuits (ICs) / Embedded - FPGAs (Field Programmable Gate Array)
Description ECP2M LFE2M20 484-BBGA Tin/Lead (Sn63Pb37) field programmable gate array 2.6mm 1.2V 420MHz 157.3kB
PDF
/
Inventory: 2021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 484-BBGA
Number of Pins 484

Technical

Operating Temperature 0°C~85°C TJ
Packaging Tray
Published 2012
Series ECP2M
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 484
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8542.39.00.01
Subcategory Field Programmable Gate Arrays
Voltage - Supply 1.14V~1.26V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 225
Supply Voltage 1.2V
Terminal Pitch 1mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LFE2M20
Pin Count 484
Number of Outputs 304
Qualification Status Not Qualified
Operating Supply Voltage 1.2V
Memory Size 157.3kB
Number of I/O 304
RAM Size 152.1kB
Programmable Logic Type FIELD PROGRAMMABLE GATE ARRAY
Number of Logic Elements/Cells 19000
Total RAM Bits 1246208
Max Frequency 420MHz
Number of LABs/CLBs 2375
Number of Logic Cells 20000

Dimensions

Height Seated (Max) 2.6mm
Length 23mm
Width 23mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Lead Free
