TMS320BC51PQA57

Texas Instruments
RoHS
RoHS RoHS compliant
Package 132-BQFP Bumpered
Category Integrated Circuits (ICs) / Embedded - DSP (Digital Signal Processors)
Description TMS320C5x MULTIPLE Contains Lead Surface Mount DSP -40C~85C TA 4.1kB 57MHz 4.608697g
PDF
/
Buying Options
Total Price: USD $47.86
Unit Price: USD $47.856565
≥1 USD $47.856565
≥10 USD $45.147699
≥100 USD $42.592177
≥500 USD $40.181286
≥1000 USD $37.906878
Inventory: 4317
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 132-BQFP Bumpered
Number of Pins 132
Weight 4.608697g

Technical

Operating Temperature -40°C~85°C TA
Packaging Tray
Series TMS320C5x
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 132
ECCN Code 3A001.A.3
Type Fixed Point
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature 1K WORDS DATA/PROG RAM
HTS Code 8542.31.00.01
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.635mm
Frequency 57MHz
Base Part Number TMS320BC51
Pin Count 132
Operating Supply Voltage 5V
Power Supplies 5V
Interface BSP, SSP, TDM
Max Supply Voltage 5.25V
Min Supply Voltage 4.75V
Memory Size 16kB
RAM Size 4.1kB
Bit Size 16
Data Bus Width 16b
Address Bus Width 16
Boundary Scan YES
Low Power Mode YES
RAM (words) 2080
Voltage - I/O 5.00V
Barrel Shifter YES
Internal Bus Architecture MULTIPLE
Non-Volatile Memory ROM (16kB)
On Chip Data RAM 4kB

Dimensions

Height Seated (Max) 4.57mm
Length 24.13mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
