EPM7128SLI84-10
RoHS
/
Package 84-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - CPLDs (Complex Programmable Logic Devices)
Description
CONFIGURABLE I/O OPERATION WITH 3.3V OR 5V 84-LCC (J-Lead) 1998 EPM7128 complex programmable logic device 125MHz 29.3116mm 10ns 3.3/55V
PDF
/
Buying Options
Total Price: USD $32.22
Unit Price: USD $32.21735
≥1 USD $32.21735
≥10 USD $26.43565
≥100 USD $25.60915
≥500 USD $24.78265
≥1000 USD $23.9571
Inventory: 1271
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 29.3116mm
Length 29.3116mm
Technical
Number of Logic Elements/Blocks 8
Delay Time tpd(1) Max 10ns
Voltage Supply - Internal 4.5V~5.5V
JTAG BST YES
Number of Macro Cells 128
Output Function MACROCELL
Number of Gates 2500
Propagation Delay 10 ns
Clock Frequency 125MHz
Number of I/O 68
Programmable Type In System Programmable
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 3.3/55V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Base Part Number EPM7128
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 220
Terminal Form J BEND
Terminal Position QUAD
Technology CMOS
Subcategory Programmable Logic Devices
Additional Feature CONFIGURABLE I/O OPERATION WITH 3.3V OR 5V
Number of Terminations 84
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e0
Series MAX? 7000S
Published 1998
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 84-LCC (J-Lead)
Mounting Type Surface Mount
