XZFMDK14A2
RoHS
RoHS compliant
RoHS compliantPackage 20-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.56" 2DIGIT RED CA SMD
PDF
/
Buying Options
Total Price: USD $6.24
Unit Price: USD $6.2392
≥1 USD $6.2392
≥10 USD $4.41056
≥100 USD $3.6124
Inventory: 182
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 16.9926mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Display Type 7-Segment
Forward Current-Max 0.03A
Wavelength - Peak 645nm
Luminous Intensity 14 mcd
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.85V
Power Dissipation-Max 75mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 2
Additional Feature IC COMPATIBLE
Color Red
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Pbfree Code yes
Size / Dimension 0.669 Hx0.988W x 0.148 D 17.00mmx25.10mmx3.75mm
Published 2014
Packaging Tape & Reel (TR)
Physical
Package / Case 20-SMD, No Lead
Supply Chain
Factory Lead Time 6 Weeks
