XAMR14A2
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 14-SEG RED 2DIGIT CA
PDF
/
Inventory: 6156
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Package / Case 18-DIP (0.600, 15.24mm)
Technical
Packaging Tube
Published 2005
Size / Dimension 0.835 Hx0.992W x 0.310 D 21.20mmx25.20mmx7.80mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Color Red
Number of Functions 2
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 75mW
Voltage - Forward (Vf) (Typ) 1.8V
Optoelectronic Device Type 14 SEG ALPHANUMERIC LED DISPLAY
Current - Test 10mA
Luminous Intensity 6 mcd
Wavelength - Peak 655nm
Forward Current-Max 0.03A
Display Type 14-Segment, Alphanumeric
Number of Characters 2
Digit/Alpha Size 0.54 13.72mm
Common Pin Common Anode
Dimensions
Height 21.209mm
Compliance
RoHS Status ROHS3 Compliant
