LB-403VF1
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.492, 12.50mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY NUM 10MM 3DIGIT RED
PDF
/
Inventory: 5994
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 16.002mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 3
Display Type 7-Segment
Forward Current-Max 0.015A
Wavelength - Peak 650nm
Luminous Intensity 6.3 mcd
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 640mW
Operating Temperature (Min) -25°C
Operating Temperature (Max) 75°C
Number of Functions 2.5
Subcategory LED Displays
HTS Code 8541.40.20.00
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e1
Size / Dimension 0.630 Hx1.024W x 0.315 D 16.00mmx26.00mmx8.00mm
Series LB-403F1
Published 2000
Packaging Bulk
Physical
Package / Case 20-DIP (0.492, 12.50mm)
