LTP-587Y
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED ALPHANUMERIC .5" YELLOW CA
PDF
/
Buying Options
Total Price: USD $2.7
Unit Price: USD $2.695384
≥1 USD $2.695384
≥200 USD $1.075265
≥500 USD $1.039817
≥1000 USD $1.022749
Inventory: 1503
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 12.7mm
Width 16mm
Length 25mm
Technical
Dominant Wavelength 588 nm
Common Pin Common Anode
Digit/Alpha Size 0.50 12.70mm
Number of Characters 1
Wavelength 588 nm
Reverse Voltage 5V
Display Type 16-Segment, Alphanumeric
Wavelength - Peak 585nm
Millicandela Rating 2.2mcd
Luminous Intensity 2.2 mcd
Forward Voltage 2.1V
Current - Test 20mA
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 60mW
Element Configuration Common Anode
Power Dissipation-Max 60mW
Number of Elements 17
Depth 16mm
Color Yellow
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.984 Hx0.630W x 0.374 D 25.00mmx16.00mmx9.50mm
Published 2000
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.500, 12.70mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
