LTM-8522E

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 3DGT ALPHA-NUM ORN 0.56"
PDF
/
Buying Options
Total Price: USD $13.64
Unit Price: USD $13.635779
≥1 USD $13.635779
≥195 USD $5.441971
≥494 USD $5.259477
≥1001 USD $5.1702
Inventory: 1510
Minimum: 1
-
+

Technical Details

Technical

Number of Elements 24
Reach Compliance Code unknown
Depth 19.05mm
Number of Functions 3
Subcategory LED Displays
HTS Code 8541.40.20.00
Additional Feature TTL COMPATIBLE
Color Orange-Red
Min Operating Temperature -20°C
Max Operating Temperature 60°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.750 Hx1.484W x 0.315 D 19.05mmx37.70mmx8.00mm
Published 2000
Packaging Tube
Dominant Wavelength 621 nm
Common Pin Serial Input
Digit/Alpha Size 0.56 14.22mm
Number of Characters 3
Display Type 7-Segment
Power Consumption 335mW
Wavelength - Peak 630nm
Illumination Color Orange
Luminous Intensity 2.4 mcd
Forward Voltage 11V
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 335mW
Min Supply Voltage 4.75V
Max Supply Voltage 11V
Configuration COMPLEX

Physical

Number of Pins 18
Package / Case 18-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 14.22mm
Height 19.05mm
