LTC-3718P
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 4DIGIT RED 0.3" CC
PDF
/
Inventory: 4999
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 8.3mm
Height 13.7922mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.34 8.50mm
Number of Characters 4
Forward Voltage-Max 2.8V
Display Type 7-Segment Clock
Forward Current-Max 0.015A
Wavelength - Peak 697nm
Millicandela Rating 0.35mcd
Luminous Intensity 350 μcd
Current - Test 20mA
Optoelectronic Device Type CLOCK LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation-Max 40mW
Reach Compliance Code unknown
Number of Functions 3.5
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.543 Hx1.378W x 0.236 D 13.80mmx35.00mmx6.00mm
Published 2000
Packaging Tube
Physical
Number of Pins 24
Package / Case 24-DIP (0.400, 10.16mm)
Supply Chain
Factory Lead Time 12 Weeks
