LTC-2623JD
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 4DGT RED
PDF
/
Buying Options
Total Price: USD $5.2
Unit Price: USD $5.200397
≥1 USD $5.200397
≥192 USD $2.075695
≥496 USD $2.006111
≥992 USD $1.971976
Inventory: 5893
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Viewing Area (height) 7mm
Height 6.096mm
Technical
Dominant Wavelength 640 nm
Common Pin Common Anode
Digit/Alpha Size 0.28 7.00mm
Number of Characters 4
Reverse Voltage 5V
Display Type 7-Segment Clock
Wavelength - Peak 656nm
Millicandela Rating 0.6mcd
Luminous Intensity 600 μcd
Current - Test 20mA
Forward Current 25mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 70mW
Element Configuration Common Anode
Number of Elements 35
Depth 10mm
Number of Functions 4
Additional Feature HIGH RELIABILITY
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.394 Hx1.191W x 0.240 D 10.00mmx30.26mmx6.10mm
Published 2001
Packaging Tube
Physical
Number of Pins 15
Package / Case 16-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
