LTC-2623E

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 16-DIP (0.300, 7.62mm), 15 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 4DIGIT ORN 0.28" CA
PDF
/
Buying Options
Total Price: USD $3.79
Unit Price: USD $3.791655
≥1 USD $3.791655
≥192 USD $1.513774
≥496 USD $1.462571
≥992 USD $1.437626
Inventory: 1284
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 7mm
Height 10.0076mm

Technical

Dominant Wavelength 621 nm
Common Pin Common Anode
Digit/Alpha Size 0.28 7.00mm
Number of Characters 4
Reverse Voltage 5V
Display Type 7-Segment Clock
Power Consumption 75mW
Wavelength - Peak 630nm
Illumination Color Red
Luminous Intensity 2 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 36
Operating Supply Voltage 2V
Depth 10mm
Number of Functions 4
Additional Feature IC COMPATIBLE
Color Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.394 Hx1.191W x 0.240 D 10.00mmx30.26mmx6.10mm
Published 2000
Packaging Tube

Physical

Number of Pins 15
Package / Case 16-DIP (0.300, 7.62mm), 15 Leads
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
