PSC08-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories AlphaNum Red 625nm Common Cathode
PDF
/
Inventory: 1320
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 18-DIP (0.600, 15.24mm)
Technical
Packaging Tube
Published 2011
Size / Dimension 1.091 Hx0.787W x 0.335 D 27.70mmx20.00mmx8.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Operating Supply Voltage 2V
Power Dissipation-Max 75mW
Element Configuration Common Cathode
Forward Current 20mA
Luminous Intensity 7.7 mcd
Millicandela Rating 7.7mcd
Wavelength - Peak 627nm
Power Consumption 75mW
Display Type 16-Segment, Alphanumeric
Forward Voltage-Max 2V
Number of Characters 1
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Cathode
Dimensions
Height 27.7114mm
Character Height 20.32mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
