PSC05-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories AlphaNum Red 625nm Common Cathode
PDF
/
Buying Options
Total Price: USD $3.55
Unit Price: USD $3.545785
≥1 USD $3.545785
≥10 USD $3.345079
≥100 USD $3.155735
≥500 USD $2.977107
≥1000 USD $2.80859
Inventory: 1208
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 18-DIP (0.500, 12.70mm)
Technical
Packaging Tube
Published 2007
Size / Dimension 0.984 Hx0.630W x 0.374 D 25.00mmx16.00mmx9.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Number of Functions 1
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 2V
Forward Current 20mA
Luminous Intensity 7.6 mcd
Millicandela Rating 7.6mcd
Wavelength - Peak 627nm
Power Consumption 75mW
Display Type 16-Segment, Alphanumeric
Number of Characters 1
Digit/Alpha Size 0.50 12.70mm
Common Pin Common Cathode
Dimensions
Height 24.9936mm
Compliance
RoHS Status ROHS3 Compliant
