DC08-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.866, 22.00mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories HI EFF RED DIFFUSED 2 DIGIT
PDF
/
Inventory: 8288
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Viewing Area (height) 20.32mm
Height 25.8572mm
Technical
Character Width 20.32mm
Dominant Wavelength 625 nm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 627nm
Luminous Intensity 8.8 mcd
Current - Test 20mA
Forward Current 30mA
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Supply Voltage 2V
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.018 Hx1.409W x 0.394 D 25.85mmx35.80mmx10.00mm
Published 2006
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.866, 22.00mm)
Supply Chain
Factory Lead Time 12 Weeks
