MAN6440
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG DUAL CC .56" GREEN
PDF
/
Buying Options
Total Price: USD $5.53
Unit Price: USD $5.52995
≥1 USD $5.52995
≥10 USD $4.53815
≥100 USD $4.39565
≥500 USD $4.2541
≥1000 USD $4.11255
Inventory: 308
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 18-DIP (0.600, 15.24mm)
Number of Pins 18
Technical
Packaging Bulk
Published 2003
Size / Dimension 0.750 Hx0.985W x 0.315 D 19.05mmx25.02mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Additional Feature IC COMPATIBLE, HIGH RELIABILITY
Subcategory LED Displays
Number of Functions 2
Depth 19.05mm
Operating Supply Voltage 5V
Number of Elements 16
Element Configuration Common Cathode
Power Dissipation 600mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 20mA
Luminous Intensity 2.2 mcd
Wavelength - Peak 565nm
Display Type 7-Segment
Reverse Voltage 6V
Number of Characters 2
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dimensions
Height 19.05mm
Viewing Area (height) 14.22mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
